BAYADOU 58.4V 3A Lifepo4 Electric Bike Fast Charger 48V 16S 20AH Lithium Iron Phosphate Energy Storage Solar Battery Chargers with fan XT60 XT90 Connector

58.4V 3A

Input:100-240V AC 50-60 Hz

Output:58.4V 3A

Power of charger:180W

Size:151*74*47MM

Color:Black

Charge Port: XT60 / XT90

Charger plug :US/EU/UK/AU Plug you can choose

Apply to:48V 16S Lifepo4 battery pack

Charge Mode:CC-CV

Charge Efficiency: >85%

Security protection: OVP/OCP/ Overload protection/ Short-circuit protection

Charge mode:  CC-CV

First stage:CC-constant current charging, the LED indicator is red. When charging to the rated voltage, it will switch to the second stage.

Second stage:CV-constant voltage charging, the current will gradually decrease until the LED indicator turn to green, and the battery has been fully charged to 90% - 95%. The battery continues to charge at a small current until it is fully charged.

LED Light:

RED ---Charging

Green---Full charged, Stop automatically and turn green when the battery is full charged.

Charger Safety:

1.Short-circuit protection
2.Over-current protection
3.Over-voltage protection
4.Over-temperature protection

Parcel include:

1pcs 58.4V 3A Lifepo4 Charger

1pcs  AC Charger plug(US/EU/UK/AU plug you can choose)
